QUEENY VISION II BLOCK B

STRUCTURE:
It is a R.C.C. framed structure of columns, beams and slabs. The internal partition walls will be of brick masonry and the external walls will be laterite masonry.

PLASTER:
External plaster will be double coat, sand faced cement plaster. Internal wall and ceiling plaster will be single coat with wall readymix.

TILING:
All rooms balconies and passage shall have Vitrified tiling and skirting. Anti-skid Ceramic tiling for the Kitchen and toilets. Full height tiles for toilet walls.

DOORS & WINDOWS:
All doors will have first class Sal Wood frames with teakwood shutters. Window frames and shutters will be of UPVC having openable arrangement. UPVC French doors for living Room. Ventilators for bathroom with Exhaust fan, M.S. grills as per our design.

KITCHEN:
Modular kitchen with cabinets above and below the kitchen platform, single bowl stainless steel sink with drain board and mixer. Ceramic tiles with kitchen motif above the kitchen platform. Electrical/Plumbing provisions for Microwave Owen, geyser and water purifier.

INTERNAL DÉCOR:
The walls will be painted with light colour Emulsion paint, celing with white Emulsion paint.

EXTERNAL DÉCOR:
External walls will be painted with exterior emulsion paint.

WATER PROOFING:
All toilets roofs will be provided with conventional type and chemical water proofing.

WATER TANKS:
A common underground sump with a common electric pump and a common overhead tank are provided.

BATHROOM:
The following sanitary fittings are provided:
1.European W.C. with flush valve/push button.
2.3 in 1 shower mixer.
3.Wash basin.
4.Health Faucet.
5.Inlet-outlet points for washing machine (if not required in kitchen)
6.Inlet-outlet points for Geyser

GENERAL:
Vitified sills for windows and balcony railings,. Lofts in kitchen & bedroom. Provision for split A/C in bedrooms.

ELECTRICAL INSTALLATIONS:
The electrical wiring will be concealed with copper wire. The following points will be given.

LIVING/DINING ROOM
1.One Chandelier point.
2.Three nos of light points.
3.Two nos of 5 amp plug points.
4.Two nos of fan points.
5.TV point.
6.Telephone point.
7.One light points and one plug point for living balcony.
8.One A/C Point.

BEDROOM
1.Three nos of light points (1 point 2 ways)
2.One fan point
3.One A/C point
4.Two nos. 5 amps plug points
5.TV point, Telephone point
6.One light point for balcony

KITCHEN:
1.Two light points
2.Two 5 amps plug point
3.Two 15 amps plug point
4.One fan point

BATHROOM:
1.Two light points
2.One 15 amps plug point
3.One 5 amps point.

PASSAGE:
1.One light point.
